Important:
Because of differences in conditions (concentration, temperature, pressure etc.) and composition of chemicals / fluids the recommended colour coding green/red/blue/black are only guidlines and should not be taken as binding. For these reasons we cannot give any guarantees as to the correctness of our recommendations in individual cases.
Back

_REA 15 AZ1

Article number: 12014201 / EAN: 7611034210742

Replaced by REA 15 AC1 (12070701)

Drehzahlgesteuertes Li-Ion Akku-Rückensprühgerät REA 15 AZ1 von Birchmeier
  • Akku-Sprühgerät gewinnt Taspo Award
  • Akku-Sprühgerät für den Privatgarten
  • Akku-Sprühgerät für den Privatgarten
  • Akku-Sprühgerät für den Privatgarten

Speed controlled battery powered backpack sprayer

Real working comfort

  • Consistent spray pattern
  • Drop size adjustable
  • "Look and feel" the ergonomics
  • Hose outlet in working direction
  • Click belt system
  • Recessed grips
  • Li-Ion battery



Electronic speed control

  • Pressure range: 15 - 44 psi
  • Protective setup for pump and battery
  • 10 h at 15 psi (~186 l)
  • 3 h at 44 psi (~104 l)



Proven Birchmeier technology

  • Robust pump
  • Tank outlet via suction system
  • Plastic/brass nozzle adjustable
  • Simple plug-in system (compression fitting)
  • Large filling opening with strainer
Read more

Technical data
Chemical resistanceFor use with the most plant protection products.Not suitable for formic acid, acetic acids, sodium / potassium hydroxides. In addition stainless steel units: no hydrochlonic acid, nitric acid, sulfuric acid or hydrofluoric acid, ammonia, peroxides and other corrosive media.Not suitable for mineral oil based and vegetable oils, hypochlorites, limonenes, terpenes.Not suitable for non-polar solvents, ketones, peroxides, chlorine, acids and alkalines.
ApplicationPesticide
Water
Biological agents
Plant protection
Herbicides
Form of applicationLiquid
Filling capacity (Volume, l)15
Max. working pressure (bar)3
Nozzle typeAdjustable nozzle 1.7 mm
Spray patternAdjustable nozzle
Nozzles materialPlastic, brass
Material Device/containerPlastic
Material FittingsPlastic, brass
Fitting connectorscompression fitting
Stress classStandard duty
Length (mm)220
Width (mm)400
Height (mm)600
Weight (kg)4.1
Device typeBattery sprayer
Special functionBattery unit 14 VElectronic speed control
Nozzles data
Adjustable nozzle 1.7 mm, PP Ms NBRAdjustable nozzle 1.7 mm, PP Ms NBRTechnical parametersSpray patternAdjustable nozzle (adjustable from spraying to jet)Pressure range15 – 363 psiFlow rate gal/minpsiDroplet size depending on pressure
Pressure (psi)152944587387102116131145
Spraying
To the nozzle
Videos

No videos available.

DownloadsLeaflet
Instructions for useInstructions for use
Safety regulationsSafety regulations
